Clarion PN-3124N-A User Manual

-13-
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
R406 119-1021-15 1/10W 1k ohm R471 119-1241-15 1/10W 120k ohm R568 116-1221-15 1/4W 1.2k ohm
R407 119-1021-15 1/10W 1k ohm R472 119-3331-15 1/10W 33k ohm R569 116-1221-15 1/4W 1.2k ohm
R408 119-4721-15 1/10W 4.7k ohm R473 119-6801-15 1/10W 68 ohm R570 119-1031-15 1/10W 10k ohm
R409 119-4721-15 1/10W 4.7k ohm R474 119-2241-15 1/10W 220k ohm R571 119-4721-15 1/10W 4.7k ohm
R410 119-4731-15 1/10W 47k ohm R489 119-4731-15 1/10W 47k ohm R572 119-1031-15 1/10W 10k ohm
R411 119-3311-15 1/10W 330 ohm R502 119-1031-15 1/10W 10k ohm R573 032-0148-50 1/10W 100k ohm
R412 119-3311-15 1/10W 330 ohm R503 119-1031-15 1/10W 10k ohm R574 032-0140-16 1/10W 180k ohm F
R413 119-4731-15 1/10W 47k ohm R504 119-1031-15 1/10W 10k ohm R575 116-2721-15 1/4W 2.7k ohm
R416 119-4731-15 1/10W 47k ohm R505 119-1031-15 1/10W 10k ohm R576 116-1531-15 1/4W 15k ohm
R417 119-4731-15 1/10W 47k ohm R507 119-1031-15 1/10W 10k ohm R577 119-0000-05 1/10W 0 ohm JW
R422 119-1011-15 1/10W 100 ohm R508 119-1031-15 1/10W 10k ohm R578 119-2221-15 1/10W 2.2k ohm
R423 119-1011-15 1/10W 100 ohm R509 119-1031-15 1/10W 10k ohm R580 116-1531-15 1/4W 15k ohm
R424 119-1011-15 1/10W 100 ohm R510 119-1031-15 1/10W 10k ohm R581 119-1031-15 1/10W 10k ohm
R425 119-1011-15 1/10W 100 ohm R511 119-0000-05 1/10W 0 ohm JW R582 119-5611-15 1/10W 560 ohm
R426 119-1011-15 1/10W 100 ohm R512 119-1031-15 1/10W 10k ohm R583 116-4791-15 1/4W 4.7 ohm
R427 119-1011-15 1/10W 100 ohm R513 119-1031-15 1/10W 10k ohm R584 116-4791-15 1/4W 4.7 ohm
R428 119-1031-15 1/10W 10k ohm R514 119-1051-15 1/10W 1M ohm R585 119-1031-15 1/10W 10k ohm
R429 119-1031-15 1/10W 10k ohm R515 119-1051-15 1/10W 1M ohm R586 119-0000-05 1/10W 0 ohm JW
R436 119-1021-15 1/10W 1k ohm R517 119-1051-15 1/10W 1M ohm R587 119-2231-15 1/10W 22k ohm
R437 119-1021-15 1/10W 1k ohm R518 119-1051-15 1/10W 1M ohm R588 119-3321-15 1/10W 3.3k ohm
R440 119-4721-15 1/10W 4.7k ohm R519 119-1031-15 1/10W 10k ohm R590 119-0000-05 1/10W 0 ohm JW
R441 119-1021-15 1/10W 1k ohm R520 119-1031-15 1/10W 10k ohm R591 119-0000-05 1/10W 0 ohm JW
R442 119-1031-15 1/10W 10k ohm R521 119-1031-15 1/10W 10k ohm R592 119-0000-05 1/10W 0 ohm JW
R443 119-4731-15 1/10W 47k ohm R522 119-1031-15 1/10W 10k ohm R593 119-0000-05 1/10W 0 ohm JW
R445 119-0000-05 1/10W 0 ohm JW R523 119-1031-15 1/10W 10k ohm R594 119-0000-05 1/10W 0 ohm JW
R446 119-4731-15 1/10W 47k ohm R524 119-1031-15 1/10W 10k ohm R595 119-4731-15 1/10W 47k ohm
R447 119-1031-15 1/10W 10k ohm R525 119-1031-15 1/10W 10k ohm R596 119-4731-15 1/10W 47k ohm
R448 119-4731-15 1/10W 47k ohm R526 119-1031-15 1/10W 10k ohm R597 119-7531-15 1/10W 75k ohm
R449 119-1021-15 1/10W 1k ohm R533 119-1031-15 1/10W 10k ohm R598 119-4731-15 1/10W 47k ohm
R450 119-1021-15 1/10W 1k ohm R534 119-1031-15 1/10W 10k ohm R943 119-1021-15 1/10W 1k ohm
R451 119-4731-15 1/10W 47k ohm R535 119-1031-15 1/10W 10k ohm SUP102 060-0122-91 DSP-141N-S00B
R452 119-4731-15 1/10W 47k ohm R540 116-6811-15 1/4W 680 ohm TH101 002-0229-00 PTH8L05BAIR8M1B
R453 119-4731-15 1/10W 47k ohm R542 032-0140-03 1/10W 220k ohm F
R454 119-4731-15 1/10W 47k ohm R543 032-0140-19 1/10W 75k ohm F
TH201 002-0229-00 PTH8L05BAIR8M1B
R455 119-2231-15 1/10W 22k ohm R548 119-2241-15 1/10W 220k ohm
T508 009-0670-81 180uH
R456 119-4731-15 1/10W 47k ohm R551 119-1031-15 1/10W 10k ohm
TM101 073-0762-90 TERMINAL
R458 119-1011-15 1/10W 100 ohm R553 119-4721-15 1/10W 4.7k ohm
TM102 073-0762-90 TERMINAL
R459 119-1011-15 1/10W 100 ohm R554 032-0140-51 1/10W 15k ohm F
TM201 073-0762-90 TERMINAL
R460 119-4721-15 1/10W 4.7k ohm R556 119-4721-15 1/10W 4.7k ohm
TM501 073-0762-90 TERMINAL
R461 119-4721-15 1/10W 4.7k ohm R557 119-4721-15 1/10W 4.7k ohm
TM502 073-0762-90 TERMINAL
R464 119-2231-15 1/10W 22k ohm R563 116-3911-15 1/4W 390 ohm
X301 061-3537-90 41.6MHz
R465 119-4731-15 1/10W 47k ohm R564 116-1221-15 1/4W 1.2k ohm
X401 061-3541-90 CRYSTAL 10MHz
R468 119-1031-15 1/10W 10k ohm R565 116-1221-15 1/4W 1.2k ohm
PWB 039-3125-00 PWB(WITHOUT
R469 119-1031-15 1/10W 10k ohm R566 119-1521-15 1/10W 1.5k ohm
COMPONENT)
R470 119-4731-15 1/10W 47k ohm R567 119-1031-15 1/10W 10k ohm
PN-3124N
