Note) Some parts depend on each model.The model name is specified in the description.
-9-
NO. PART NO. DESCRIPTION Q'TY NO. PART NO. DESCRIPTION Q'TY
1 940-8420-29 ES-ASSY 1 27 074-1302-12 OUTLET SOCKET 1
2 947-0591-00 KNOB ASSY 1 28 331-3880-00 TR HOLDER 1
3 347-7959-00 SHADE 1 29 313-1980-00 HEAT SINK 1
4 380-5655-10 KNOB 1 30 716-1646-50 IT SCREW (M2.6 x 8) 1
5 ----------- SWITCH PWB 1 31 307-0720-00 REAR PLATE 1
6 335-7693-00 LCD HOLDER 1 32 073-0762-90 TERMINAL 5
7 335-7801-00 LCD LEFLECTOR 1 33 778-3006-00 SCREW (3 x 6) 4
8 379-1392-52 INDICATOR (LCD) 1 34 714-2608-8B
MACHINE SCREW (M2.6 x 6)
7
9 331-4166-00 LCD COVER 1 35 345-5805-01 GASKET 1
10 016-7004-00 ROTARY SWITCH 1 36 311-1914-00 LOWER CASE 1
11 013-6201-52 TACT SWITCH 15 37 313-1967-00 HEAT SINK 1
12 013-6202-52 TACT SWITCH 9 38 716-0878-50 SCREW (M2.6 x 5) 5
13 074-3013-72 OUTLET SOCKET (22P) 1 39 309-0822-00 ES PLATE (6CD) 1
14 074-3013-66 OUTLET SOCKET (16P) 1 40 929-0390-82 CD MECH MODULE 1
15 345-8090-00 CUSHION RUBBER 1 41 331-4092-10 CD MECH BRKT (RH) 1
16 716-0778-52 WAVE SCREW (2 x 6) 10 42 331-4091-10 CD MECH BRKT (LH) 1
17 716-0872-51 PAD SCREW (M1.7 x 5) 2 43 716-3552-00 SCREW (M2.3 x 2.5) 6
18 345-5805-01 GASKET 1 44 816-4024-50 FLAT WIRE 1
19 ----------- MAIN PWB 1 45 310-1823-10 UPPER CASE 1
20 074-1237-69 OUTLET SOCKET (19P) 1 46 735-2614-1B
MACHINE SCREW (M2.6 x 14)
2
21 076-0478-59 PLUG (9P) 1 47 714-2606-8B
MACHINE SCREW (M2.6 x 6)
10
22 076-3011-72 PLUG (22P) 1 48 276-0034-75 SET PLATE (PN-3124N-A) 1
23 076-3011-66 PLUG (16P) 1 276-0034-76 SET PLATE (PN-3124N-B) 1
24 880-2091M TUNER PACK 1 49 060-8062-50 CERAMIC-ANT 1
25 092-2210-01 ANT RECEPT 1 50 060-8079-90 BLUETOOTH MODULE 1
26 074-4009-20 OUTLET SOCKET 1
PN-3124N

Clarion PN-3124N-A Specifications

General

Brand	Clarion
Model	PN-3124N-A
Category	Car Stereo System
Language	English
