-12-
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
IC107 051-7255-08 SN74AHC1G66 Q403 191-0709-00 2SB709A Q,R,S R210 119-1021-15 1/10W 1k ohm
HDCKR Q404 192-2712-00 2SC2712 R212 119-3331-15 1/10W 33k ohm
IC204 051-3340-00 LD1085P Q503 125-2027-91 DTC114EUA R215 119-4731-15 1/10W 47k ohm
IC205 051-3516-90 S-1132B33-U5T1G Q504 191-1197-50 2SB1197K Q,R R220 119-1041-15 1/10W 100k ohm
IC301 ---------- SAF7730HV/N317 Q506 125-2027-91 DTC114EUA R224 119-4721-15 1/10W 4.7k ohm
IC402 ---------- M30876FJBGP Q507 191-1197-50 2SB1197K Q,R R227 119-4721-15 1/10W 4.7k ohm
IC404 051-5417-08 S-80927CNMC-G8X Q509 193-2118-00 2SD2118F5 Q,R,S R229 119-4721-15 1/10W 4.7k ohm
IC406 051-9425-80 S-24CS64A0I-J8T1G Q512 125-2027-91 DTC114EUA R233 119-4721-15 1/10W 4.7k ohm
IC501 051-3019-90 NJM2060V Q515 193-1664-00 2SD1664 P,Q,R R248 116-2201-15 1/4W 22 ohm
IC502 051-3518-90 NJM2846DL3-33- Q516 192-4116-51 2SC4116 G,L R249 032-0140-98 1/10W 330 ohm F
TE1 Q517 191-1204-61 2SB1204 R,S,T R250 116-1221-15 1/4W 1.2k ohm
IC503 051-2042-00 TA8275H Q518 125-2027-91 DTC114EUA R251 032-0140-93 1/10W 2k ohm F
IC504 051-3396-90 NJM2386ADL3-33- Q519 191-1197-50 2SB1197K Q,R R252 119-1031-15 1/10W 10k ohm
TE1 Q520 192-4116-00 2SC4116 R301 119-1031-15 1/10W 10k ohm
IC505 051-3517-90 LT3481EMSE Q521 192-4081-00 2SC4081 R302 119-1031-15 1/10W 10k ohm
#TRPBF Q522 125-2027-91 DTC114EUA R303 119-2201-15 1/10W 22 ohm
IC506 051-5441-08 BD4828G-TR Q523 192-4081-00 2SC4081 R304 032-0140-80 1/10W 18k ohm F
J201 074-1302-12 TH12P-SOCKET R103 119-3321-15 1/10W 3.3k ohm R305 032-0140-80 1/10W 18k ohm F
J202 074-1237-69 19PIN R106 119-0000-05 1/10W 0 ohm JW R306 032-0140-80 1/10W 18k ohm F
J502 074-4009-20 SOCKET(20P) R109 119-3321-15 1/10W 3.3k ohm R307 032-0140-80 1/10W 18k ohm F
L105 010-2003-04 30uH R111 119-3321-15 1/10W 3.3k ohm R314 119-1011-15 1/10W 100 ohm
L106 010-3104-54 600 ohm/100MHz R112 119-0000-05 1/10W 0 ohm JW R315 119-1031-15 1/10W 10k ohm
L107 010-3104-54 600 ohm/100MHz R113 119-3321-15 1/10W 3.3k ohm R316 119-1021-15 1/10W 1k ohm
L108 010-2198-50 0.15uH R116 119-2741-15 1/10W 270k ohm R 317 119-1031-15 1/10W 10k ohm
L301 010-3104-54 600 ohm/100MHz R117 119-3331-15 1/10W 33k ohm R318 119-3921-15 1/10W 3.9k ohm
L302 010-3104-54 600 ohm/100MHz R118 119-3931-15 1/10W 39k ohm R319 119-1031-15 1/10W 10k ohm
L303 010-3104-54 600 ohm/100MHz R121 119-3931-15 1/10W 39k ohm R320 119-3921-15 1/10W 3.9k ohm
L304 010-3104-54 600 ohm/100MHz R122 119-1031-15 1/10W 10k ohm R321 119-1031-15 1/10W 10k ohm
L305 010-3104-54 600 ohm/100MHz R123 119-1031-15 1/10W 10k ohm R322 119-0000-05 1/10W 0 ohm JW
L306 010-3104-54 600 ohm/100MHz R124 119-3931-15 1/10W 39k ohm R323 119-1031-15 1/10W 10k ohm
L307 010-3104-54 600 ohm/100MHz R125 119-1031-15 1/10W 10k ohm R324 119-1041-15 1/10W 100k ohm
L308 010-3104-54 600 ohm/100MHz R126 119-1011-15 1/10W 100 ohm R325 119-1041-15 1/10W 100k ohm
L309 010-3104-54 600 ohm/100MHz R127 119-4731-15 1/10W 47k ohm R326 119-1001-15 1/10W 10 ohm
L310 010-3104-54 600 ohm/100MHz R128 119-4731-15 1/10W 47k ohm R327 119-3921-15 1/10W 3.9k ohm
L311 010-3104-54 600 ohm/100MHz R129 119-4731-15 1/10W 47k ohm R328 119-0000-05 1/10W 0 ohm JW
L312 010-3104-54 600 ohm/100MHz R130 119-8221-15 1/10W 8.2k ohm R329 119-1021-15 1/10W 1k ohm
L313 010-3104-54 600 ohm/100MHz R131 119-1011-15 1/10W 100 ohm R330 119-3921-15 1/10W 3.9k ohm
L402 010-3406-54 2.2uH J R132 119-1011-15 1/10W 100 ohm R331 119-0000-05 1/10W 0 ohm JW
L501 010-3104-54 600 ohm/100MHz R134 119-1031-15 1/10W 10k ohm R332 032-0140-50 1/10W 10k ohm F
L503 010-3414-90 6.8uH R135 119-2231-15 1/10W 22k ohm R334 032-0140-50 1/10W 10k ohm F
P101 076-3011-66 16P R136 116-6891-15 1/4W 6.8 ohm R336 032-0140-50 1/10W 10k ohm F
P401 076-0478-59 PLUG (9P) R138 119-1031-15 1/10W 10k ohm R337 032-0140-50 1/10W 10k ohm F
P402 076-3011-72 22P R139 119-1041-15 1/10W 100k ohm R 338 032-0140-50 1/10W 10k ohm F
Q101 198-3018-00 2SK3018 R140 119-1001-15 1/10W 10 ohm R339 032-0140-50 1/10W 10k ohm F
Q102 198-3018-00 2SK3018 R141 119-1031-15 1/10W 10k ohm R340 032-0140-50 1/10W 10k ohm F
Q104 125-9017-92 UMD3N-TR R143 119-2231-15 1/10W 22k ohm R341 119-1031-15 1/10W 10k ohm
Q105 125-2027-91 DTC114EUA R144 119-2231-15 1/10W 22k ohm R342 119-1031-15 1/10W 10k ohm
Q106 125-2027-91 DTC114EUA R145 119-1001-15 1/10W 10 ohm R343 119-1031-15 1/10W 10k ohm
Q107 125-2027-91 DTC114EUA R146 119-1031-15 1/10W 10k ohm R344 119-1011-15 1/10W 100 ohm
Q108 125-2027-91 DTC114EUA R148 116-1091-15 1/4W 1 ohm R345 119-1011-15 1/10W 100 ohm
Q109 192-5886-00 2SC5886 (PN-3124N-A) R346 119-0000-05 1/10W 0 ohm JW
Q110 125-2027-90 DTC143EU R149 116-1221-15 1/4W 1.2k ohm R347 119-0000-05 1/10W 0 ohm JW
(PN-3124N-A) (PN-3124N-A) R348 119-0000-05 1/10W 0 ohm JW
Q111 190-2060-00 2SA2060 R150 116-3911-15 1/4W 390 ohm R349 119-0000-05 1/10W 0 ohm JW
(PN-3124N-A) R151 119-1031-15 1/10W 10k ohm R350 119-1031-15 1/10W 10k ohm
Q112 125-9017-92 UMD3N-TR (PN-3124N-A) R351 119-0000-05 1/10W 0 ohm JW
Q201 192-4081-00 2SC4081 R153 119-1041-15 1/10W 100k ohm R352 119-4731-15 1/10W 47k ohm
Q204 125-9017-92 UMD3N-TR R162 119-0000-05 1/10W 0 ohm JW R353 119-1021-15 1/10W 1k ohm
Q206 198-3018-00 2SK3018 R165 119-1031-15 1/10W 10k ohm R354 119-1021-15 1/10W 1k ohm
Q207 198-3018-00 2SK3018 R166 119-1031-15 1/10W 10k ohm R355 119-1021-15 1/10W 1k ohm
Q219 125-2027-90 DTC143EU R167 119-1031-15 1/10W 10k ohm R356 119-1021-15 1/10W 1k ohm
Q220 191-1197-50 2SB1197K Q,R R168 119-1031-15 1/10W 10k ohm R357 119-4731-15 1/10W 47k ohm
Q222 125-9017-92 UMD3N-TR R169 119-1031-15 1/10W 10k ohm R358 119-1001-15 1/10W 10 ohm
Q301 125-7007-90 Si5441BDC-TI-E3 R170 119-1031-15 1/10W 10k ohm R359 119-4731-15 1/10W 47k ohm
Q302 125-2027-91 DTC114EUA R171 119-0000-05 1/10W 0 ohm JW R360 119-4731-15 1/10W 47k ohm
Q303 125-2027-91 DTC114EUA R172 119-0000-05 1/10W 0 ohm JW R361 119-4731-15 1/10W 47k ohm
Q304 125-2027-91 DTC114EUA R173 119-1531-15 1/10W 15k ohm R362 119-4731-15 1/10W 47k ohm
Q305 125-2027-91 DTC114EUA R174 119-2231-15 1/10W 22k ohm R400 119-0000-05 1/10W 0 ohm JW
Q306 125-2027-91 DTC114EUA R175 119-1021-15 1/10W 1k ohm R401 119-1021-15 1/10W 1k ohm
Q307 125-2027-91 DTC114EUA R176 119-3931-15 1/10W 39k ohm R402 119-1021-15 1/10W 1k ohm
Q308 125-2027-91 DTC114EUA R177 119-6821-15 1/10W 6.8k ohm R403 119-1021-15 1/10W 1k ohm
Q401 125-2027-91 DTC114EUA R207 119-3011-15 1/10W 300 ohm R404 119-0000-05 1/10W 0 ohm JW
Q402 125-0021-91 DTA114EUA R208 119-3011-15 1/10W 300 ohm R405 119-1021-15 1/10W 1k ohm
PN-3124N
