12
ENGLISH
Signal Distribution Con’t
XC6420 Input Selection Switch
• 4 Channel - Routes all inputs direct to all outputs. Channel 1 to Output 1, etc.
• 2 Channel - Copies the input of Channel 1 to Channel 3 and Channel 2 to
Channel 4. This can be used to drive all 4 channels with only a single pair of
input connections.
• 2 Channel Bass Boost - Similar to 2 Channel mode, but allows the Bass
Boost circuit to affect Channel 3 and Channel 4.
XC6420 Mode Select Switch
• Stereo - Audio signals are passed through to the outputs unaltered.
• Mono - Sums the input of both channels equally and sends identical
signals to the outputs. This function operates independently on each pair of
channels.
• Bridged - On Channels 1 and 2, in Bridged mode, the input of Channel 1 is
sent to the outputs of both channels 1 and 2. On Channels 3 and 4, the input
of Channel 2 is sent to the outputs of both channels 3 and 4. With both Mode
Select switches set to Bridged, the XC6420 becomes a 2 x 250W 2-channel
amplifi er.
XC6620 Input Selection Switch
• 6 Channel - Routes all inputs directly to all outputs. Channel 1 to Output 1,
etc.
• 4 Channel - The inputs of Channels 1 through 4 are directly sent through the
amplifi er unaltered. Channel 5 is fed from the sum of channels 1 and 3 while
channel 6 is fed from the sum of channels 2 and 4.
• 2 Channel - Input 1 is copied to Input 3 and Input 5. Input 2 is copied to
Input 4 and Input 6. This allows a single pair of interconnects to feed all six
channels.
