Clarion XC6420 User Manual

19
ENGLISH
Specifi cations
XC6620
Frequency Response: <10Hz to 74kHz
4 Ohm Stereo Power Output (CEA-2006A) 85W x 6 @ 1.0% THD
2 Ohm Stereo Power Output (CEA-2006A) 125W x 6 @ 1.0% THD
4 Ohm Bridged Power Output (CEA-2006A) 250W x 3 @ 1.0% THD
Signal to Noise Ratio (CEA-2006A) @ 1W/4 Ohms > -88 dBA
Effi ciency at Full Power (4 Ohms) 83.2%
Input Sensitivity 200mV to 6V
Crossover Range 50Hz to 500Hz
Crossover Slope -12dB/Octave HPF or LPF
2.16” 55mm
6.82” 173.3mm
11.35” 288mm
2 X 35 AMP MAX
+12V
GND
REM
POWER
PROTECT
4 CH INPUT
6 CH.
4 CH.
INPUT SELECT
ON
OFF
AUTO SENSE
CH5-6
BASS
BOOST
2 CH.
BRIDGED
4
CH1
CH2
CH3
CH4
BRIDGED
4
2 CH INPUT
4
CH5
CH6
0
12
dB
BRIDGED
GAIN
MIN
MAX
FREQ Hz
50
110
500
330
240
HIGH
FULLLOW
330
CH4
CH3
CH2
CH1
CH6
CH5
GAIN
MIN
MAX
FREQ Hz
50
110
500
330
240
HIGH
FULLLOW
GAIN
MIN
MAX
FREQ Hz
50
110
500
HIGH
FULLLOW
240
