5-6
Tilting the mast forward
•
Push the control lever (1) forward.
Tilting the mast back
• Pull the control lever (1) back.
Raising the fork carriage
Do not step on the raised forks.
Increased danger of falling and
being squeezed.
• Push control lever (1) to the right.
Lowering the fork carriage
• Push control lever (1) to the left.
Operating the attachments (Optional)
Attachments (e.g. sideshifter, clamp, etc.) can
be fitted on the lift truck as optional equipment.
Observe the operating pressure and instruc-
tions for the attachment. One additional con-
trol lever is fitted for its operation.
For each attachment, affix a load
capacity label for the truck with
attachment to the battery cover and
affix a symbol label at the rear of
the appropriate control lever.
Operating the sideshifter (Optional)
• Push control lever (2) to the left (this will move the sideshifter to
the left).
• Push control lever (2) to the right (this w
ill move the sideshifter
to the right).
Operating the clamp (Optional)
• Push control lever (2) forward (this will open the clamp).
• Pull control lever (2) back (this
will close the clamp).
Attachments not supplied with the truck may only be employed
if an authorized distributor ascertains that a safe operation is
assured in respect to load capacity and stability.
