5-7
Section 5. Operating Procedures
Using the Display
LCD Back Light (ECX)
• LCD back light is linked to the Key switch.
When the start key turns on. The LCD back
light will illuminate.
DISPLAY Initial Start-up (
ECX)
• KEY ON
- All the Icons and Buzzers
will be ON for 1 second to check the
indicating conditions.
- Seat belt warning alarms for 5 seconds after Icon turns off for 1
s
econd: It is always indicated regardless of communicating with
controllers; When this mode is working, all the indicating data
should be in normal conditions.
"(Working hour/speed, Battery discharging rate, Speed limit rate,
Pa
rking)"
• After seat belt warning mode is
working, the data supplied from
controller will be indicated.
The display should turn "ON" all symbols and "8888" appears on
numeric display
for about 2 seconds when the key switch is turned
"ON". After 2 seconds, all displays should return to normal operating
conditions except seat belt reminder symbol which will continue to be
displayed for 3 additional seconds(5 seconds total) while the seat
belt buzzer (alarm) sounds.
If the battery symbol light comes on, the digital readout shows the
p
ercentage of charge remaining on the battery. When the remaining
charge registers as 20% or less, the readout flashes. At 10%
remaining charge, the lift and tilt functions become inoperable.
If the wrench symbol comes on, a status code appears on the digital
r
eadout. The status code may indicate an easily correctable
"operator fault" or it may indicate that you need to have the truck
serviced. If you see a status code, use the table below as a guide.
Codes -01 through -06 are usually the operator errors. Any other
code is a service code
Character indicator & Speed meter (ECX)
•
Error code & travel
speed are indicated at
sa
me position.
