5-10
Positioning Forks and Upright
Lift Control
Lever
Tilt Control
Lever
When driving, with or without a load, it
is good practice to have the forks
sl
ightly raised and tilt the upright (forks)
backward. Having the forks raised and
tilting back prevents the fork tips from
catching on possible obstructions and
reduces the wear on the fork blades
from striking or dragging on the floor or
ground. See the NOTICE and
CAUTION below.
Pull back on the lift c
ontrol lever and
raise the forks 6 - 8 in (152 - 203 mm)
above the floor. Then, using the tilt
control, tilt the upright back slightly to
raise the fork tips.
When the upright (carriage and/or load) is raised, the sta-
bility of the truck is reduced. Some of the other conditions
tha
t may affect stability are: ground and floor conditions,
grade, speed, loading, dynamic and static forces and the
judgment exercised by the operator. Trucks equipped with
attachments behave as partially loaded trucks even when
operated without a load on the attachment. Also, improper
operation, faulty maintenance or poor housekeeping may
contribute to a condition of instability.
For stability reasons, do not travel with the load or
carriage in a highly elevated position. Travel with the lift
mechanism raised only enough to clear the ground or
obstacles.
If your truck starts to tip over, DO NOT JUMP! Your
chances for survival in a tip-over are better if you stay
with the truck, in your seat. BRACE YOURSELF!. Make
sure your seat belt is fastened securely. Stay in your seat.
Grip the wheel. Brace your feet. See page 1-14
