3-8 Pod Symbols and Functions
• Glow plug Preheat (Diesel truck)
Indicates glow plugs are in the process of
preheating the diesel engine. When the
ignition switch is turned to the “ON”
position, a timer is set. This symbol
displays until the timer cycle is completed.
The engine may then be started.
•Seat belt
At start-up, this light and a buzzer come
on for three seconds to remind the
operator to fasten the seat belt. There is no
start interlock.
You should always have your seat belt
securely fastened when operating your lift truck.
• Parking brake
Indicates that the parking brake is
engaged. Anytime the parking brake is on,
the truck can’t be driven because the
Transmission solenoid valves switch is off.
When the parking brake is not set and the
key switch is turned to the OFF position,
the instrument pod will sound.
If the parking brake is set, buzzer and horn will not sound.
