Operator Controls 3-49
Section 3. Operator Compartment and Controls
Fuse
The fuses are located at the inside of the foot
well, on the right when looking forward.
The fuse ratings are visible on the fuses.
CAUTION
The fuse box lid contains the legend
list of what the fuses are for and what
their ratings are. Always replace fuses
with the same current rating. Never put
higher rated fuse in.
Fuse Specification
Truck Engine Type
ISUZU YANMAR FORD PSI
F1 Sub Controller 10A
F2 Sub Controller 10A
F3 Parking 5A
F4 Turn signal 10A
F5 Horn 10A
F6 Speed Limit Control 15A
F7 Brake 5A
F8 Power Jack 10A
F9 Spare 10A
F10 Spare 30A
(20A)
F11
Fuel Pump 5A
Actuator 20A
F12
ECM 30A
(10A)
Engine Shutdown 30A
F13 Engine Shutdown 15A
F14 Additional - Option Power 5A
F15 Room Lamp & Audio (option) 10A
F16
Cabin - option (W/D) 20A
Starter 20A
Defogger (option) 20A
FUSE BOX
F1 F11 F21
F2 F12 F22
F3 F13 F23
F4 F14 F24
F5 F15 F25
F6 F16 F26
F7 F17 F27
F8 F18 F28
F9 F19 F29
F10 F20 F30
