C346
4
04/2010
CAV 50 - CAV 100
US
Vacuum cleaner description
Optional kits
Please contact the manufacturer’s sales network for
information on optionals.
Instructions for installing the optionals are included in the
conversion kit.
WARNING!
Use only supplied and authorized genuine spare parts.
Accessories
Various accessories are available; refer to the manufacturer’s
accessory catalogue.
WARNING!
Use only genuine accessories supplied and
authorized by the manufacturer.
Packing and unpacking
Dispose of the packing materials in compliance with the laws
in force.
Figure 3
Model
CAV 50
(50L)
CAV 100
(100 L)
A (in) 27.6 27.6
B (in) 33.9 33.9
C (in) 68.9 68.9
Weight with packaging (lbs.) 176 196
Unpacking, moving, use and storage
Operate on fl at, horizontal surfaces.
The load-bearing capacity of the surface the vacuum cleaner
is placed on must be suitable for bearing its weight.
Vacuum Cleaner Parts and Labels
Figure 1
Model code, Technical Specifi cations (see table on page 1.
6), Serial N°., CE Mark, Year of manufacture, Nominal
voltage.
Dust container2.
Dust container release lever3.
Inlet4.
Accessories compartment7.
Exhaust air outlet8.
Attention plate: Draws the operator’s attention to 9.
the fact that the fi lter must only be shaken when the
vacuum cleaner is turned off (see also par. “Primary fi lter
shaker”).
Plug for connecting the vacuum cleaner to an electrical 10.
socket.
Figure 2
This vacuum cleaner creates a strong air fl ow which is drawn
in through the inlet (4 - Fig. 1) and blown out through the
exhaust outlet (9 - Fig. 1).
Before turning on the vacuum cleaner, fi t the vacuum hose
into the inlet and then fi t the required tool on to the end part
(refer to the manufacturer’s accessory catalogue or Service
Centre).
The diameters of the authorized hoses are given in the
technical specifi cations table.
The vacuum cleaner is equipped with a primary fi lter which
enables it to be used for the majority of applications.
Besides the primary fi lter, which retains the most common
types of dust, the vacuum cleaner can be fi tted with a HEPA
fi lter with a higher fi ltering capacity for fi ne dusts and dusts
that are hazardous to health.
