SPECIFICATION
Motor Supply 230Vac/ 50Hz / 1ph
Motor 470 W
Fuse link rating 5 Amp
Product Weight 51 kg
Operating temperature
0
o
- 40
o
Sound Pressure Level 82 dB LpA
Max drill Capacity 13 mm
End mill capacity 16mm
Face mill capacity 30mm
Mill/Drill head angle
-45 to +45
o
Spindle Taper MT3
Table effective size 92mm x 400mm
Table cross travel 100mm
Table longitudinal travel 235mm
Spindle to Column 170mm
Overall dimensions 514 x 506 x 756mm
Spindle Speed Range 0-2500 rpm
