1. Technical specifications
1.1 Hardware
Items Features
Operating Temperature
0to40℃
Operating Relative Humidity 10-90% (Non condensing)
Storage Temperature
-40to70℃
Dimensions (H x W x D) 218 x 155 x 55mm
Diagnostic LED
，
s (Front) POWER, US, DS, ONLINE, 2.4G, 5G, TEL1, TEL2
Diagnostic LED
，
s(Rear)
Ethernet Link/Speed
1.2 Interfaces
Items Features
RF Interface External ‘F’ type connector
Data Interfaces 4 x 10/100/1000 Base-T Ethernet (RJ-45 connector)
Analog Telephony Interface 2 lines, RJ-11
Input Voltage 100~240VAC, 50/60 Hz
1.3 Downstream
Items Features
Bonded Channels Up to 24
Tuner Configuration Full capture tuning range
Frequency Range 108~1002 MHz
Data Rate (Max.) Up to 1320 Mbps
RF Input Sensitivity Level -15 to +15 dBmV
Modulation Type 64QAM and 256QAM
