Clarson PUBLIC III - System Connectivity; Connect CS60 to PUBLIC III Central Unit; Connect CS60 Base Station to Mains

Central Unit
Ref. 40.054.311
patch cable with
RJ45 / RJ10 modular jack
(8-pole / 4-pole)
Ref. 40.054.378
Connecting the CS60 Headset System
to the PUBLIC III Central Unit
2 7
Notes:
RJ45
8-pole
RJ10
4-pole
Mains Connection
CS60 Base Station
- bottom side -
CS60 Base Station
Ear-loop &
Over-the-hed style
Ref. 40.030.004
