CleanMaster 100-041-017 - SPECIFICATIONS AND DIMENSIONS

Mnl50005 (02-03) 12
OPERATION
SPECIFICATIONS
MACHINE DIMENSIONS
Model EXPRESS MULTI SURFACE CLEANER
LENGTH 1308 mm (51.5 in)
WIDTH 406 mm (16 in)
HEIGHT 1047.7 mm (41.25 in)
WEIGHT 71.6 Kg (158lbs)
SOLUTION TANK CAPACITY 45 L (12 gal)
RECOVERY TANK CAPACITY 45L (12 gal)
SOLUTION PUMP 120 V, 4.13 bar (60psi), .7 A
VACUUM MOTOR – 3 STAGE @120 V, 10.6A, 1272 W
SEALED WATER LIFT 2718 mm (107 in)
HEAD SPEED 130 RPM
HEAD MOTOR 120V, 1/2HP, 5.6 A, 672W
TOTAL POWER CONSUMPTION 120V, 13.8 A, 1656W
POWER CORDS 1 @ 15.2m (50 ft) 3/12
DECIBEL RATING 3 METERS (10 FT) FROM
MACHINE ON CARPET
<67 db(A)
1308
mm
(51.5 in)
10
47.7
mm
(41.25 in)
4
06.4
mm
(16 in)
9
20.7
mm
(36.25 in)
