EN
18
No water is emerging from the
nozzles.
The spray button (8) has not been
pressed.
► Press the spray button on the handle
to activate the spray function.
The fresh water tank (13) is empty.
► Fill the fresh water tank.
The suction hose with handle has not
been correctly attached / connected to
the nozzles.
► Check and correct all connections
where necessary.
The nozzles are blocked.
► Switch off the device and remove the
blockage.
A strange odour is produced.
The device is being used for the first time.
► A new odour is normal when the
device is used for the first time; it
disappears after a while.
DISPOSAL
Dispose of the packaging material
in an environmentally friendly
manner so that it can be recycled.
The adjacent symbol (crossed-out
bin underlined) means that used
devices should not be disposed
of in the domestic waste, but
should instead be taken to special
collection and return systems.
Owners of used devices from
private households can take
them free of charge to the
collection points of the public
waste disposal authorities or the
disposal points which are set up
by manufacturers and distributors
under the Electrical Equipment
Act. Businesses which market
electrical and electronic devices
are also obliged to take back
used devices.
TECHNICAL DATA
Article number: 04982
ID of operating instructions: Z 04982 M DS V1 0522 as
Model number: YLW6336
Voltage supply: 220 – 240 V; 50 / 60 Hz
Power: 400 W
IP protection type: IP X4
Protection class: II
Capacity of dirty water tank: 0.5 L to MAX marking
Capacity of fresh water tank: 1.1 L to MAX marking
Length of suction hose: 1.2 m
Length of cable: 3 m
Suction force: approx. 9 kPa
Operating volume: approx. 85 dB
All rights reserved.
