Section A – Specifications
Shown: ClearWater Tech CD1500P Ozone Generator
27” h x 9.25” w x 5.5” d, 32 lbs
15g/h, 6% @ 6 scfh, 10PSI
PSA Oxygen
Mounting Hole Measurement
Drive Board and Drive
Transformer (under board)
Reaction Chamber
Power Supply
Inline Particulate Filter
4-20mA Control Board
Pressure Switch
Cover Safety Switch
External Loop
Remote 4-20mA Control Leads
Ozone Output LED
Pressure Gauge
CFH Gauge
Air Prep Inlet
Manual Ozone Output Adjustment Knob
Ozone Outlet Needle Valve
Main Power Light
Power Entry Module – OFF/ON
Switch, Cord Input, Fuse Carrier
Bonding/Ground Lug
Fan and Fan Filter
External Loop Connector
Remote 4-20mA Connector
