Quick reference to topologies
Quick reference to cable capacity and distance
Clear-Com recommends Belden 9207 for fixed
installation, and Belden 9463F for portable installations.
Tip: The attenuation of a cable increases with distance, and this can impact audio quality. If your
priority is audio quality, experiment with attaching one or two fewer devices to each line. For in-depth
cabling advice, contact your Clear-Com representative.
Copyright © 2015 HME Clear-Com Ltd. All rights reserved.
Optional
redundancy flyback
1
10
2
3456789
XLR
Bulkhead
(passive)
1
2
3
4
5
6
7
89
Mult-box
(passive)
Daisy chain
Star configuration
