ClearOne WS880 - Transmitter Types: Table-Top and Podium; Table-Top Microphone Features

10
1. Power LED: When the Table Mic is on, the LED signals:
Red = audio mute.
Green = audio passes.
Blinking Red = battery low.
Blinking Green = sync successful.
2. Contacts: Contact points for the charging station.
3. I/R Sensor: Inputs programming instructions and encryption
key from the receiver.
4. Power Switch: On / Off.
5. USB Port: Doubles as the power supply / recharger
connection and computer programming port. The
transmitter operates normally under USB power, with dead
or no batteries for permanent installations.
The ClearOne WS800 Table-top Microphone combines the professional audio specs and security of a wired mic
with wireless convenience. Available in omni or cardioid polar pick-up patterns with 265-bit FIPS 197 encryption.
ClearOne Gooseneck Podium Mic Stems are available in 6”, 12” and 18”
lengths that are interchangeable and field replaceable.
The Gooseneck mic capsule is available with a cardioid polar pattern.
1. Interchangeable microphone capsule.
2. Flexible stem section.
3. A 4-pin XLR connector allows the exchange of different length
microphone stems.
TABLE-TOP MICROPHONE:
PODIUM GOOSENECK STEM :
GOOSENECK MIC CAPSULE:
CARDIOID
pickup pattern
Transmitters:
1
3 2 2
2
3 4
5
2
1
Capsules are field replaceable.
