20" ACCESS OPENING
SURGE
CONTROL
WEIR
CLARIFIER
AIR LINE
CONDUIT
AERATION
CHAMBER
TWO (2) DIFFUSERS
HIGH WATER
LEVEL ALARM
3
4
" S/40 PVC AIR LINE FROM AERATOR
4" S/40 PVC
OUTLET
4" S/40 PVC
INLET
WALL THICKNESS
INLET
OUTLET
A
B
C
D
F
G
E
20" ACCESS OPENING
12" ACCESS OPENING
CLEARSTREAM
AERATOR
(TYP 2)
CLEARSTREAM
CLEARSTREAM
CLEARSTREAM
HIGH LEVEL ALARM
MODELS
1000NCD
1200NCD
1500NCD
A
B C
D E
F
75"
146"
153"
155"
82"
82"
60"
60"
71"
143"
151"
153"
58"
58"
68"
18"
18"
18"
G
3"
3"
3"
NOTE:
SOME MODELS MAY NOT BE
AVAILABLE AT ALL LOCATIONS.
DIMENSIONS:
.
.
.
.
DESIGN DRAWINGS
NCD 1000-1500 SERIES OWNERS MANUAL PAGE 9
