9.4 — Parts Lists and Drawings
Blast Tube Assembly Quantity
Item
No.
Part No. Description 42 54 63 84 105 145 175 210 252 300 315 336
1 8-1029 Bracket, 23” Support, Standard
Panel
222222
8-1275 Bracket, 28” Support, Standard
Panel
22 22 22
2 817-829 Switch, Pressure, Air Oil, 4-12 psi *1 *1 *1 *1 *1 *1
3 40-377 Housing Assembly, Firing Head 1 1 1
40-378 Housing Assembly, Firing Head 1 1
40-400 Housing Assembly, Firing Head 1
40-381 Housing Assembly, Firing Head 1
40-382 Housing Assembly, Firing Head 1
40-380 Housing Assembly, Firing Head 111
40-410 Housing Assembly, Firing Head 1
4 8-1025 Bracket, Safety Interlock Switch 1 1 1 1 1 1 1 1 1 1 1 1
5 836-301 Switch, Safety Interlock 1 1 1 1 1 1 1 1 1 1 1 1
6 32-1127 Seal (varies)
7 19-485 Cover, Firing Head Access 1 1 1
19-486 Cover, Firing Head Access 1 1
19-487 Cover, Firing Head Access 1
19-489 Cover, Firing Head Access 1 1
19-488 Cover, Firing Head Access 1111
8 31-36 Glass, Flame Sight 1 1 1 1 1 1 1 1 1 1 1 1
9 869-184 Nut, Sight Glass 1 1 1 1 1 1 1 1 1 1 1 1
10 85-885 Support Assembly, Burner 1 1 1 1 1
85-886 Support Assembly, Burner 1 1
85-887 Support Assembly, Burner 11111
*DLG
