750-204
Profire D/LND
9-13
9.4 — Parts Lists and Drawings
Blower Housing Assemblies Quantity
Item
No.
Part No. Description 378 420
1 894-1368 Blower Motor 11
2 515-16 Seal Plate 11
3 85-813 Shroud Assembly, Air Hood 11
4 85-891 Support, Motor and Air Damper 11
5 91- Spacer (varies) 11
6 192-327 Impeller Assembly 11
7 869-185 Nut, Hex Lock 1-3/8” 12 UNF 11
8 152-17 Pad, Blower Motor Mounting 11
9 836-336 Switch, Air Pressure 11
10 85-892 Support Assembly, Damper to Motor 11
11 152-18 Pad, Motor Support 11
12 265-142 Stator Cone Assembly 11
13 19-530 Access Cover 11
14 914-205 External Retaining Snap Ring 11
15 56-290 Hinge Pin 11
16 43-13 Latch Toggle Clamp 22
17 40-403 Fan Housing Assembly 11
18 32-1060 Gasket, Fan Housing Seal 11
