Parts Lists and Drawings
9-42
750-204
Profire D/LND
Oil Metering Assemblies Quantity
Item
No.
Part No. Description 42 54 63 84 105 145
1 894-1289 Motor, 1 HP, Models DL, DLG 1 1 1 1
894-1295 Motor, 2 HP, Models DL, DLG 11
894-1289 Motor, 1 HP, Models DM, DMG 1 1
894-1295 Motor, 2 HP, Models DM, DMG 1111
2 40-296 Housing, Mounting Oil Pump to Motor 1 1 1 1 1 1
3 19-342 Cover, Drive Coupling Access 2 2 2 2 2 2
4 819-114 Coupling, Drive Models DL, DLG 1 1 1 1
819-105 Coupling, Drive Models DL, DLG 11
819-114 Coupling, Drive Models DM, DMG 1 1
819-105 Coupling, Drive Models DM, DMG 1111
5 923-115 Filter, Air 11 11 11
6 695-90 Meter & Compressor Assembly, Oil-Air #5-4 Models DL, DLG 1
695-92 Meter & Compressor Assembly, Oil-Air #6-4 Models DL, DLG 1
695-94 Meter & Compressor Assembly, Oil-Air #7-4 Models DL, DLG 1
695-100 Meter & Compressor Assembly, Oil-Air #8-4 Models DL, DLG 1
695-90 Meter & Compressor Assembly, Oil-Air #5-4 Models DM, DMG 1
695-92 Meter & Compressor Assembly, Oil-Air #6-4 Models DM, DMG 1
12 695-64 Meter & Compressor Assembly, Oil-Air #5-5 Models DM, DMG 1
12 695-66 Meter & Compressor Assembly, Oil-Air #7-5 Models DM, DMG 1
7 287-1 Arm, Assembly 11 11
8 17-143 Coil Assembly, Cooling 1111
9 8-1572 Bracket, Cooling Coil, Mounting 22
8-1260 Bracket, Cooling coil, Mounting 22
10 923-115 Filter, Air 11 11 11
11 940-1169 Valve, Check 1/2” Horizontal 11
12 695-101 Meter & Compressor Assembly, Oil-Air #7-6 E Style Models DL, DLG 1
695-78 Meter & Compressor Assembly, Oil-Air #8-6 E Style Models DL, DLG 1
6 695-90 Meter & Compressor Assembly, Oil-Air #7-7 E Style Models DM, DMG 1
6 695-92 Meter & Compressor Assembly, Oil-Air #6-4 E Style Models DM, DMG 1
13 282-13 Stop Assembly, Override, Metering Head 1 1 1 1 1 1
14 476-53 Linkage Assembly, Limiting Arm, 9 Holes 5/16” 1 1 1 1 1 1
15 940-1142 Valve, Oil Solenoid 3/8” 2 Way N.C. 1 1 1 1
940-1372 Valve, Oil Solenoid 1/2” 2 Way N.C. 11
16 940-1224 Valve, Relief 1/2” 60 PSI 1 1 1 1 1 1
17 940-1347 Valve, Oil Solenoid 3/8” 3 Way N.C. 1 1 1 1
940-1348 Valve, Oil Solenoid 1/2” 3 Way N.C. 11
To Next Page
