Parts Lists and Drawings
9-44
750-204
Profire D/LND
Oil Metering Assemblies Quantity
Item
No.
Part No. Description 42 54 63 84 105 145 175 210 252 300 315 336
1 894-934 Motor, 1/2 HP 1 1 1 1 1 1 1
894-936 Motor, 3/4 HP 11111
2 40-296 Housing, Mounting Oil Pump to
Motor
111111111111
3 19-342 Cover, Drive Coupling Access 2 2 2 2 2 2 2 2 2 2 2 2
4 819-114 Coupling, Drive 9/16” X 5/8” Bore 1 1 1 1
819-105 Coupling, Drive 5/8” X 5/8” Bore 1 1 1 1 1 1 1 1
5 695-80 Metering Head Ass’y, Oil #30L 1
695-70 Metering Head Ass’y, Oil #40L 1 1
695-71 Metering Head Ass’y, Oil #60L 1
695-81 Metering Head Ass’y, Oil #75L 1
695-72 Metering Head Ass’y, Oil #100L 1
695-82 Metering Head Ass’y, Oil #125L 1
695-73 Metering Head Ass’y, OIl #150L 1
695-83 Metering Head Ass’y, Oil #180L 1
695-74 Metering Head Ass’y, Oil #200L 1
695-75 Metering Head Ass’y, Oil #350L 11
6 282-13 Stop Ass’y, Override, Metering
Head
111111111111
7 476-53 Linkage Ass’y, Limiting Arm, 9
Holes 5/16”
111111111111
8 940-1372 Valve, Oil Solenoid 1/2” 2 Way
N.C. DL
11 11 11
Valve, Oil Solenoid 1/2” 2 Way
N.C. DM
11 11 11
Valve, Oil Solenoid 1/2” 2 Way
N.C. DE
111111111111
9 940-1348 Valve, Oil Solenoid 1/2” 2 Way
N.C. DL
11
Valve, Oil Solenoid 1/2” 2 Way
N.C. DM
11
Valve, Oil Solenoid 1/2” 2 Way
N.C. DE
11111111
940-1233 Valve, Oil Motorized W/POC. DE 1111
Valve, Oil Motorized W/POC. DM 1111
Valve, Oil Motorized W/POC. DE 1111
10 940-1224 Valve, Relief 1/2” 60 PSI 1 1 1 1 1 1 1 1 1 1 1 1
