Clemco ZERO BNP 55 - 2.3 Connect Compressed-Air-Supply Lines; 2.4 Ground the Cabinet and Dust Collector

BNP
®
55 SUCTION BLAST CABINET Page 3
© 2019 CLEMCO INDUSTRIES CORP.  www.clemcoindustries.com  Manual No. 23350, Rev G, 02/19
Figure 1
Some item removed or rotated for clarity.
On-Off Switch
Air-Inlet Damper
Dust Drum
LED Light
CDC-1 Dust Collector
Door Interlock Valve
Reclaimer
600 cfm reclaimer shown.
300 cfm reclaimer does not
have flanged bolt-on top or
hopper.
Debris Screen
Blow-Off
Nozzle
Metering Valve
Li
g
ht-Lined Flex Hose
Air Filter
(Attachment for
compressed-air supply).
Grounding Lug
Unlined Flex Hose
Pilot Regulator
Pilot-Operated
Pressure Regulator
To Blast Gun
To Blo
w
-Off Nozzle
BNP Blast Gun
Auxiliary Air Port (plugged)
Use for pneumatic accessories.
120-Volt Cord
Arm Ports
Dust-Collector Damper
Door Interlock Actuator
Foot Pedal
