Cleveland DC - Wiring to Power Source and Switching

Wiring Instructions
1. Be sure all the equipment is all rated for the same voltage
2. Be sure the negative battery terminal is properly grounded to the
truck chassis.
3. Connect the positive battery terminal to the large input terminal on
the solenoid using AWG #6 cable or heavier.
4. Ground the small input terminal on the solenoid to the truck chassis
or the negative battery terminal using AWG #16 wire or heavier.
5. Connect the large output terminal of the solenoid to the power
terminal on the vibrator using AWG #6 cable or heavier. The DC
Electric Vibrator Accessory kits include the solenoid and 25 feet of
cable with the necessary terminal and connectors to do this.
6. Connect the appropriate switch to the small output terminal on the
solenoid using AWG #16 wire or heavier. Use a push button switch
for intermittent use and a pull on switch for continuous use. The
appropriate switch is included in the DC Electric Vibrator Accessory
kits.
7. Connect the other side of the switch to the positive battery terminal
using AWG #16 wire or heavier.
8. Connect the ground terminal found on the end cover of the vibrator
motor to the mount channel or truck bed using AWG #6 cable or
WIRING TO POWER SOURCE AND SWITCHING
ALL wires and cables connecting to the vibrator should have some
slack.
The vibrator must be properly grounded. A heavy duty ground cable
or strap should be used to complete the electrical circuit between
the truck bed and the truck frame to insure proper grounding and
operation.
For non-truck applications, mount the solenoid & switch where most
convenient.
CAUTION!
12 Volt Battery
OR
24 Volt Battery
12 Volt Vibrator 24 Volt Vibrator
12 Volt Solenoid 24 Volt Solenoid
