Clevo N150RD - Removing the M.2 SSD Module

Disassembly
Removing the M.2 SSD Module 2 - 13
2.Disassembly
Removing the M.2 SSD Module
1. Turn off the computer, remove the battery (page 2 - 5), and bottom case (page 2 - 6).
2. The M.2 SSD module will be visible at point on the mainboard (Figure 9a).
3. Remove the screw
(Figure 9b)
4. The M.2 SSD module (Figure 9c) will pop-up, and you can remove it from the computer.
5. Reverse the process to install a new SSD (make sure that the hexagonal screw is in the correct location). Note that
a flat-head screw driver can be used to tighten or remove the hexagonal screw as shown (Figure 9d).
1
2
3
b.
c.
a.
2
3
1
3

3.M2 SSD Module
•1 Screw
Figure 9
M.2 SSD Module
Removal
a. Locate the M.2 SSD.
b. Remove the screw.
c. The M.2 SSD module
will pop up.
