Introduction
Specifications 1 - 3
1.Introduction
Pointing Device
Built-in Touchpad
Interface
Four USB 3.0 Ports
One
Mini DisplayPort
One HDMI-Out Port
One External Monitor Port
One Headphone-Out Jack
One Microphone-In Jack
One S/PDIF Out Jack
One RJ-45 LAN Jack
One DC-in Jack
M.2 Slots
Slot 1 for M.2 2230 WLAN Combo Module Card with PCIe &
USB Interfaces
Slot 2 for M.2 2280 SSD Card with SATA/ PCIe x2/ x4 Inter-
face
Communication
Built-In Gigabit Ethernet LAN
(Factory Option) 2.0M FHD PC Camera Module
WLAN/ Bluetooth M.2 Modules:
(Factory Option) Intel® Wireless-AC 7265 Wireless LAN
(802.11ac) + Bluetooth 4.0
(Factory Option) Intel® Wireless-N 7265 Wireless LAN
(802.11b/g/n) + Bluetooth 4.0
(Factory Option) Intel® Wireless-AC 3160 Wireless LAN
(802.11ac) + Bluetooth 4.0
(Factory Option) Qualcoumm® Atheros Killer™ Wireless-AC
1525 Dual Band 2x2 AC +BT M.2 1630
(Factory Option) Third-Party Wireless LAN 802.11b/g/n +
Bluetooth 4.0
Card Reader
Embedded Multi-In-1 Card Reader
MMC (MultiMedia Card) / RS MMC
SD (Secure Digital) / Mini SD / SDHC/ SDXC
Environmental Spec
Temperature
Operating: 5
°C - 35°C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Power
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 19.5V, 6.15A (120W)
Built-in 6 Cell Smart Lithium-Ion Battery Pack, 62WH
Dimensions & Weight
413mm (w) * 285mm (d) * 31.9mm (h)
2.9kg (Barebone with 62WH Battery)
