Latest Specification Information
The specifications listed here are correct at the
time of sending them to the press. Certain items
(particularly processor types/speeds) may be
changed, delayed or updated due to the manu-
facturer's release schedule. Check with your
service center for more details.
CPU
The CPU is not a user serviceable part. Ac-
cessing the CPU in any way may violate your
warranty.
Processor Options
Intel® Pentium® Processor
N4200 (1.10GHz)
2MB Smart Cache, 14nm, DDR3L-1866MHz, TDP 6W
Intel® Celeron® Processor
N3450 (1.10GHz), N3350 (1.10GHz)
2MB Smart Cache, 14nm, DDR3L-1866MHz, TDP 6W
BIOS
64Mb SPI Flash ROM
AMI BIOS
Memory
Two 204 Pin SO-DIMM Sockets Supporting DDR3L 1600/
1866MHz Memory
Memory Expandable up to 8GB
Compatible with 4GB or 8GB Modules
(The real memory operating frequency depends on the FSB
of the processor.)
LCD Options
14" (35.56cm), 16:9, HD (1366x768)/FHD (1920x1080)
(Thickness: 3.6mm)
Video Adapter
Intel GPU (CPU integrated)
Intel HD Graphics 505 (Pentium CPU integrated)
Dynamic Frequency
Intel Dynamic Video Memory Technology
Microsoft DirectX®12 Compatible
Intel HD Graphics 500 (Celeron CPU integrated)
Dynamic Frequency
Intel Dynamic Video Memory Technology
Microsoft DirectX®12 Compatible
Storage
One Changeable 2.5" 7mm (h) SATA HDD/SSD
(Factory Option) One M.2 SATA Solid State Drive (SSD)
(Factory Option) 32GB eMMC*
*Note: Systems with 32GB eMMC modules only support
Windows 10 Hybrid Boot.
Pointing Device
Built-in Touchpad
Keyboard
“WinKey” keyboard (with embedded numeric keypad)
Audio
High Definition Audio Compliant Interface
2 * Built-In Speakers
Built-In Microphone
Or
(Factory Option) Built-In Array Microphone
Security
Security (Kensington® Type) Lock Slot
BIOS Password
Intel PTT for Systems Without TPM Hardware
(Factory Option) TPM 2.0
M.2 Slots
Slot 1 for WLAN and Bluetooth Combo Module
(Factory Option) Slot 2 for SATA SSD or 3G/4G Module
