2 - 10 Removing the System Memory (RAM)
2.Disassembly
8. Replace the bay cover and screws (make sure you reconnect the fan cable before screwing down the bay
cover).
Note that there are four - cover pins which need to be aligned with slots in the case, to insure a proper cover
fit, before screwing down the bay cover.
9. Restart the computer to allow the BIOS to register the new memory configuration as it starts up.
Figure 6
RAM Module
Removal (cont’d.)
d. Properly re-insert the
bay cover pins.
