Clevo W310CZ-T - External Locator - Top View with LCD Panel Open

Introduction
1 - 4 External Locator - Top View with LCD Panel Open
1.Introduction
External Locator - Top View with LCD Panel Open
Figure 1
Top View
1. PC Camera
(Optional)
2. Built-In Microphone
3. *PC Camera LED
(1M HD Camera
Only)
*When the PC
camera is in use,
the LED will be
illuminated in red
4. LCD
5. Power Button
6. Keyboard
7. Touchpad & Buttons
5
7
6
2
1
3
4
