9
OPERATION INSTRUCTIONS
1. Plug unit into power socket, unit will beep
twice.
2. Press POWER button to turn unit on.
The dry air outlet air deflector will open
and the blue backlight will illuminate and
turn off after 15 seconds. The LCD display
will show the working mode, status of unit,
ambient humidity and temperature.
NOTE
The dehumidification setting is automatically
set on continuous and default fan speed is
set at High (H).
NOTE
The dry air outlet air deflector will close when
unit is turned off. Press power button to turn
unit off.
3. MODE button sets up Continuous/
Automatic dehumidifying modes and Fan
speed.
4. SETTING button confirms the running
fan speed or Continuous/Automatic
dehumidifying ratio.
5. To set automatic dehumidifying relative
humidity (RH) ratio, press MODE button
until LCD display lights up on the icon
. Press SETTING button to select relative
humidity (RH) ratio in 5% increments
between 40% - 80%, and then press MODE
to set selection, or three seconds after
pressing SETTING the desired humidity
ratio is set and the indicator light will stop
illuminating
NOTE
When setting unit on automatic
dehumidification, the continuous
dehumidifying mode will be cancelled.
PRODUCT SPECIFICATIONS CLI-DH20-E AIR DEHUMIDIFICATION SYSTEM
DEHUMIDIFICATION 20 LITRES/DAY
DEHUMIDIFYING CAPACITY 0.83 kg/hour
AIR CIRCULATION 140 cbm/hour
POWER CONSUMPTION 340 watts
CAPACITY OF WATER TANK 3.8 L
REFRIGERANT R134a (150 g)
NOISE LEVEL ≤46dB
N.W 12.8 kgs
G.W 14.0 kgs
PRODUCT DIMENSIONS 350 x 242 x 586 mm
