INSTALLATION - USER - MAINTENANCE MANUAL

Water-cooled liquid chillers

GB

BRH FF

0011÷0121

Questions and Answers

B
Brent SalazarAug 13, 2025
Why is my CLIMAVENETA Chiller not starting?
- F
  fwardAug 13, 2025
  Your CLIMAVENETA Chiller might not be starting due to several reasons. There could be no voltage, in which case you should check the presence of voltage and safety systems upstream of the appliance. Alternatively, a contactor coil, the HSW12 controller, or the start-up capacitor (if featured) might be faulty, requiring component replacement. Other potential causes include a faulty compressor or reversed phases (for three-phase units).
C
Cynthia PhillipsAug 17, 2025
What causes high discharge pressure in CLIMAVENETA Chiller?
- K
  Kenneth KingAug 17, 2025
  High discharge pressure (greater than 32 bars) in your CLIMAVENETA Chiller can be caused by high outside water temperature. If this occurs, you should check the water temperature. It may also be due to a high utility water inlet temperature.
T
Thomas KnappAug 21, 2025
What causes low suction pressure in CLIMAVENETA BRH 0091 FF?
- J
  jordandavidAug 21, 2025
  Low suction pressure (less than 4 bars) in a CLIMAVENETA Chiller can stem from several factors. These include a low utility water inlet temperature, a low outside water inlet temperature, or a faulty or blocked thermostatic expansion valve, so you should check these components. It may also be caused by a blocked water filter or a blocked plate heat exchanger.
J
Jacqueline ArnoldAug 25, 2025
How to fix noise and vibrations in CLIMAVENETA BRH 0091 FF Chiller?
- T
  Timothy VazquezAug 26, 2025
  Noise and vibrations in your CLIMAVENETA Chiller can be caused by contact between metal bodies; you should check for this. Another cause may be loose screws, so tighten them.
C
Charles NicholsAug 28, 2025
Why is the compressor noisy in my CLIMAVENETA Chiller?
- D
  Dean VegaAug 28, 2025
  A noisy compressor in your CLIMAVENETA Chiller may be caused by liquid returning to the compressor, which you should check. Another possible cause is inadequate fastening.
S
sdoyleSep 1, 2025
What causes high suction pressure in CLIMAVENETA BRH 0091 FF?
- K
  Kevin JacobsonSep 1, 2025
  High suction pressure (greater than 20 bars) in your CLIMAVENETA Chiller could be due to a high utility water inlet temperature or a faulty or excessively open thermostatic expansion valve. In such cases, you should check these components.
B
Benjamin FrankSep 5, 2025
What causes low discharge pressure in CLIMAVENETA BRH 0091 FF Chiller?
- T
  tstewartSep 5, 2025
  Low discharge pressure (less than 16 bars) in a CLIMAVENETA Chiller can be caused by a low utility water inlet temperature, so you should check this.
J
jenningsdeniseSep 8, 2025
What to do if there is moisture in the refrigerant circuit of CLIMAVENETA BRH 0091 FF?
- R
  Rhonda RobinsonSep 8, 2025
  If there is moisture in the refrigerant circuit of your CLIMAVENETA Chiller (indicated by a yellow flow indicator), you should empty and refill the system.

Summary

General Safety and Handling

General Warnings

General safety precautions and manufacturer liability.

Fundamental Safety Rules

Essential safety rules for operating electrical and water equipment.

Receiving and Handling the Product

Procedures for receiving, unpacking, and handling the unit.

Dimensional Drawings

Installation and Water Connections

Installation Site Selection

Guidelines for choosing the installation site and positioning the unit.

Water Circuit Connections

Requirements and diagrams for connecting water circuits.

Filling and Emptying the System

Step-by-step guides for filling and emptying the water circuit.

Electrical Connections

Electrical Connections Overview

Instructions for mains and auxiliary electrical connections.

Electrical Panel Identification

Diagram and identification of components within the electrical panel.

Power Supply and Auxiliary Connections

Specifics for mains power, auxiliary, and remote connections.

Technical Data and Operating Conditions

General Technical Data

Comprehensive technical specifications for various unit models.

Operating Limits

Defines the operational temperature ranges and limits for the unit.

Operating Characteristics

Details on how the unit operates under various conditions.

Unit Control and Settings

Checking and Starting Up

Procedures for initial checks and starting the unit.

HSW12 Controller Functions

Overview of the HSW12 controller and its functions.

Display and LEDs

Explanation of the controller's display and status LEDs.

Selecting Operating Mode

How to switch between Standby and Cooling modes.

Setting Set Points

Guide to adjusting cooling and heating set points.

Setting Parameters

Steps to access and modify unit parameters via the PASS directory.

Compressor;Pump Hours

How to view and reset operating hours for compressors and pumps.

Maintenance and Troubleshooting

Routine Maintenance

Scheduled maintenance tasks to ensure efficiency and longevity.

Special Maintenance

Specific maintenance tasks like chemical flushing and refrigerant handling.

Troubleshooting

Common faults, their causes, and recommended solutions.

Useful Information

Contact and Support

Contact details for technical assistance and spare parts.

CLIMAVENETA BRH 0091 FF Specifications
