Clint MEA 1302-B User Manual

9
R134a
(1) Referential conditions at page 6.
TECHNICAL DATA
4202-B 4402-B 4802-B 5402-B 6002-B 6603-B 7203-B 8103-B 9003-B MODEL
Cooling:
905 1015 1140 1282 1433 1566 1733 1909 2168 kW
Cooling Capacity (1)
262 296 327 364 417 456 498 550 631 kW
Absorbed power (1)
2 2 2 2 2 3 3 3 3 n°
Compressors
2 2 2 2 2 3 3 3 3 n°
Refrigerant Circuits
6 6 6 6 6 9 9 9 9 %
Capacity steps
Evaporator:
43,24 48,49 54,47 61,25 68,47 74,82 82,80 91,21 103,58 l/s
Water ow
57 55 56 52 69 78 57 67 95 kPa
Pressure drops
150 200 200 200 200 250 250 250 250 DN
Water connections
255 455 535 510 500 590 700 735 700 dm³
Water volume
Compressor:
131 148 163 182 208 152 166 183 210 kW
Unitary absorbed power (1)
230 260,0 290,0 320,0 365,0 270,0 291,0 320,0 370 A
Unitary absorbed current (1)
20 23 25 25 25 23 25 25 25 Kg
Oil charge
Connections
2x76 2x76 2x89 2x89 2x89 3x76 3x89 3x89 3x89 Ø mm
Suction line
2x54 2x54 2x54 2x54 2x54 2x54 2x54 2x54 2x54 Ø mm
Liquid line
Standard version:
85 90 91 95 97 93 95 96 99 dB(A)
Sound pressure level - DIN (1)
74 78 79 83 85 80 82 83 87 dB(A)
Sound pressure level - ISO (1)
4300 4300 5100 5100 5100 4800 5300 5300 5300 mm
Unit lenght
1080 1080 1080 1080 1080 1600 1600 1600 1600 mm
Width
2100 2100 2100 2100 2100 2100 2100 2100 2100 mm
Height
3225 3525 4445 4530 4600 4980 6430 6555 6740 Kg
Unit transport weight
SSL version:
80 85 86 90 92 --- --- --- --- dB(A)
Sound pressure level - DIN (1)
69 73 74 78 80 --- --- --- --- dB(A)
Sound pressure level - ISO (1)
4300 4300 5100 5100 5100 --- --- --- --- mm
Cooling only unit lenght
1080 1080 1080 1080 1080 --- --- --- --- mm
Width
2100 2100 2100 2100 2100 --- --- --- --- mm
Height
3675 3975 4945 5030 5100 --- --- --- --- Kg
Cooling only unit transport weight
Total electrical consumption:
<- - - - - - - - - - - - - - - - - - - - - - - - - - 400 / 3 / 50 - - - - - - - - - - - - - - - - - - - - - - - - - -> V/Ph/Hz
Power supply
558 642 740 832 935 963 1110 1248 1403 A
Max. Current
732 916 1073 1199 1344 1237 1443 1615 1811 A
Starting current
