Service Parts List C9
POS Description Req P/N
1 Blade Shaft (Alone) 1 83280
2 Nut Blade Shaft ¾'' Lefthand Thread 1 227156
3 Bearings Blade Shaft (1) with Hardware 2 72474
Screw M12 x 70 1.75 DIN931(ea) 2 27175
Washer M12 DIN125 (ea) 16 27505
Lock Washer M12 DIN127 (ea) 8 27581
Nut M12 1.75 DIN934(ea) 4 27007
Screw M12 x 45 1.75 DIN933 (ea) 2 27088
4 Blade Shaft Pulley 1 83511
5 Collar Tight (Inner Collar) 1 227159
6 Collar Loose Assembly (With Pin) 1 227247
7 Belts XPA 710 LW (Set of 3) 1 83480
8 Belt Guard Complete 1 83485
Screw M10 x 25 1.5 DIN931 (ea) 3 149044
Washer M10 DIN125 (ea) 5 27504
Lock Washer M10 DIN125 (ea) 3 27502
Nut M10 1.5 DIN934 (ea) 3 27006
Cage Nut M10 1.5(ea) 3 27189
Nut Close M10 Hex Acorn Nut (ea) 2 30177A
Washer M10 DIN125 (ea) 27504
9 Blade Guard Flap w/Hardware 1 81164
Screw M10 x 25 1.5 DIN933 (ea) 2 149044
Washer M10 Large Dia DIN9021(ea) 2 27504A
Washer M10 DIN125 (ea) 2 27504
Nut M10 1.5 DIN934 (ea) 2 27006
10 Blade Guard Complete w/Hardware 1 83481
Screw M10 x 35 1.5 DIN933 (ea) 1 27030A
Nut M10 1.5 DIN934 (ea) 1 27006
11 Stop Switch 1 227115
12 Belt Tensioning Screws (Compelte Set) 1 80994
Screw M10 x 80 1.5 DIN931 (ea) 2 27068
Eye Bolt M10 x 40 1.5 DIN444 (ea) 2 27270
Nut M10 Thin 1.5 DIN439 (ea) 2 27004
Nut M10 1.5 DIN934 (ea) 6 27006
Lock Washer M10 DIN127 (ea) 4 27502
Washer M10 DIN125 (ea) 6 27504
13 Engine Frame Welded (No Hardware) 1 83279
14 Motor Pulley Complete 1 73230
15 Honda Motor 9 HP GX270 1 73110
16 Y piece 1 72286
17 Adapter ½ Hose Barb to ¾” Garden
Hose
1 232076
18 Motor Fixing Plate w/Hardware 1 83482
Nut M10 1.5 DIN934 (ea) 8 27006
Lock Washer M10 DIN127 (ea) 8 27502
Washer M10 DIN125 (ea) 4 27504
Washer M10 Large Dia DIN9021(ea) 4 27504A
19 Water Nozzle (2) 1 82998
20 Axle Blade Guard 1 83490
21 Blade Guard Nut 1 83366
22 Valve Ball 1/2" Brass 1 107859
23 Fit 1/2mpt X3/4 F Garden Hose Swivel 1 227116
Service Parts List C9
POS Description Req P/N
24 Fit Barb Hose 3/4MPT X 1/2M 1 9600017
25 RaiseTube (No Hardware) 1 83276
Screw M12 x 80 1.75 DIN933 (ea) 1 27088
Nut Lock M12 1.75 DIN985 (ea) 2 27017
Nut M12 1.75 DIN934 (ea) 4 27581
26 Wrench 1''1/2 1 83314
27 Wrench 32mm 1 82910
28 Wrench 17mm 1 72279
29 Handle Grip (ea) 2 213633
30 Tank Cap 1 82794
31 Tap-Water Tank 1 72357
32 Water Tank Complete w/Cap 1 83357
33 Raise Axle w/Hardware 1 83486
Screw M10 x 60 1.5 DIN931 (ea) 2 27030B
Nut M10 1.5 DIN934 (ea) 2 27006
34 Front Wheel Complete (ea) 2 80992
Washer M16 DIN127 (ea) 4 27532
Pin Cotter 5/32 x 1 (ea) 2 27030C
35 Rear Wheel 200mm x 20mm (ea) 2 80991
Washer M20 DIN125 (ea) 2 27504B
Pin Cotter 5/32 x 1-1/2 (ea) 2 27030D
36 Rear Axle Fixing Flat (ea) 2 80998
Screw M10 x 30 1.5 DIN933 (ea) 4 27030
Nut M10 1.5 DIN934 (ea) 4 27006
Lock Washer M10 DIN125 (ea) 4 27502
Washer M10 DIN125 (ea) 8 27504
37 Ring Diam. 20 1 80999
38 Water Tank Bracket w/Hardware 1 83277
Screw M10 x 25 1.5 DIN933 (ea) 2 149044
Nut M10 1.5 DIN934 (ea) 2 27006
Lock Washer M10 DIN125 (ea) 2 27502
Washer M10 DIN125 (ea) 4 27504
39 Handle For Hand Wheel (No
Hardware)
1 73428
40 Hand Wheel with Handle and
Hardware
1 76357
Nut Closed M16 2 DIN1587 (1) 1 27176
Washer M16 DIN125 (1) 1 27532
Lock Washer M16 DIN127 (1) 1 27545
41 Guide-A-Cut 1 80448
42 Handle Bar Complete w/Hardware 1 83484
Screw M10 x 25 1.5 DIN933 (ea) 1 149044
Screw M10 x 20 1.5 DIN933 (ea) 1 27106
Nut M10 1.5 DIN934 (ea) 2 27006
43 Bearing w/Hardware 1 76670
Screw M10 x 30 1.5 DIN933 (ea) 2 27030
Nut M10 1.5 DIN934 (ea) 2 27006
Lock Washer M10 DIN125 (ea) 2 27502
Washer M10 DIN125 (ea) 4 27504
44 Stop Ring A20 1 82789
45 Depth Lock 1 83354
46 Depth Screw w/Key 1 82788
