CLIVET CAS-182 - Page 34

34
11 - TECHNICAL INFORMATION
1450
780
95
1260
95
3
11
400 ** 400 **
17
1450
1980
106
282
44
340
R
M
Rp
Mp
Ri
4
7
16
12
13
9
10
15
14
2
5
8
Mf
6
54
238
138
138
500
54
54
18
6
11
Rp
Mp
15 4 15 4
400 **
1142
504
19
1342
1000**
(1) COMPRESSOR
(2) ELECTRICAL PANEL
(3) ACCESS TO THE ELECTRICAL PANEL
(4) SUPPLY FAN
(5) DIRECT EXPANSION COIL
(6) PLATE EXCHANGER
(7) G4 AIR FILTERS
(8) WATER COIL (OPTIONAL) - RE-HEATING COIL (OPTIONAL)
(9) 3 WAYS-VALVE (OPTIONAL)
(10) ELECTRIC HEATERS (OPTIONAL)
(11) POWER INPUT
(12) HOT WATER HEAT EXCHANGER WATER OUTLET Ø 3 / 4 "
(13) HOT WATER HEAT EXCHANGER WATER INLET Ø 3 / 4 "
(14) EXCHANGER WATER OUTLET Ø1" 1/2 GAS
(15) EXCHANGER WATER INLET Ø1" 1/2 GAS
(16) CONDENSATE DISCHARGE
(17) FUNCTIONAL CLEARANCES
(18) WATER CONNECTION SIDE
(19) FRONT OUTLET PLENUM (OPTIONAL)
(R ) AMBIENT AIR INTAKE STANDARD
(M ) AIR SUPPLY STANDARD
(MP ) REAR AIR OUTLET (OPTIONAL)
(MF) FRONT AIR OUTLET (OPTIONAL)
(RP ) REAR AIR INLET (OPTIONAL)
(RI ) FLOOR AIR INLET (OPTIONAL)
(**) CLEARANCE ACCESS RECOMMENDED
11.4 DIMENSIONS 122 - 162
SIZE 122
Weight kg 400
162
410
