CLIVET MSAN-XMi 140M - A = Indoor Units Standard Cooling Capacity in Kw X

MSAN-XMi 200T - 260T
Size Power supply Reference kW Factory code
200T
400V+N 3-phase
20 MDV-V200W/DRN1
224T
400V+N 3-phase
22.4 MDV-V224W/DRN1
260T
400V+N 3-phase
26 MDV-V260W/DRN1
Contents pag
Installation manual ………………………………………………………………………….. 5
Owner’s manual ……………………………………………………………………………… 19
This manual is for VRF SYSTEM.
To get complete and clear information, please also consider following issues:
1. please consider only 50 Hz electric supply mode
2. Installation Manual, Table 4-3 and Table 4-4:
A = indoor units standard cooling capacity in kW x 10
3. model identification
For 1 outdoor unit connected to 1 indoor unit applications please consider the following instructions.
 Schematics refer to multiple indoor unit design:
for 1 to 1 application please consider the first indoor unit only (first line branch pipe is not needed)
 Installation Manual, Table 4-3 and Table 4-4:
for 1 to 1 application no branch pipe is needed
 Installation Manual, Table 4-8: only for VRF System
for 1 to 1 application please consider 50% ÷ 100% indoor capacity range
 Installation Manual, Chapter 4.6: only for VRF System
 Installation Manual, Table 4-11: only for VRF System
for 1 to 1 application please consider Table 4-10 data
 Owner's Manual, Chapter 1.:
for 1 to 1 application please consider 50% ÷ 100% indoor capacity range
