Wiring

Wiring Figure

One-two models:

NOTE:Use the magnetic ring ( not supplied, optional

part) to hitch the connective cable of indoorand

outdoor units after installation.One magnetic ring

is used for one cable.

e Page 20 f

POWER

6833/<

L(A)

S(A)

N(A)

L(B)

N(B)

S(B)

Y/G

/

NOTE: Refer to the following gures if end-users wish to perform their own wiring.

Run the main power cord through the lower line-outlet of the cord clamp.

CAUTION

Connect the connective cables to the terminals, as identied, with their matching numbers on the

terminal block of the indoor and outdoor units. For example, in the models shown in the

following diagram, Terminal L1(A) of the outdoor unit must connect with terminal L1 on the

indoor unit.

Model A

Model E Model F Model G

Model B Model C Model D

OPTIONAL

CLIVET MU1-Y Series User Manual
