M07J40G8-00 21/07/08 page 11
!
Tree
Consider clearances and direction of expelled air.
Keep the coil clean. Avoid
zones with leaves / dirt /
corrosives.
Avoid snow build-up during
winter operation
!
Provide windbreaks in locations with strong winds.
INSTALLATION OF ANTIVIBRATION MOUNTS
MINIMUM DIMENSIONS
SUGGESTED
CONCRETE FOUNDATION
JACK
PLATE
* UNLOADED HEIGHT
CLAMPS DROWNED IN T
