M07J40G8-00 21/07/08 page 17
MENU NUM Parameter name meaning
1 EnCompExt
External compensation enabling
0 = no; 1 = COOL only; 2 = HEAT only; 3 = always
4 MaxCExtC Max. ext. compensation value of cooling
106 CextMaxC Max. ext. temp. of cooling compensation
parameter
control
compext
107 CextMinC Min. ext. temp. of cooling compensation
parameter-set-sensors 9 ProbeText It enables ext. temp. probe: 0=yes ; 1=no
SUMMER
p4
p106 p107 Text °C
set COMPENSATO
EXTERNAL AIR HUMIDITY PROBE - Optional
It allows the automatic correction of the set-point, according to external air enthalpy .
Nel funzionamento invernale la correzione avviene sulla sola temperatura.
The working process is similar to the above mentioned process . The parameter configuration is necessary.
MENU NUM Parameter name meaning
4 MaxCExtC Max. Summer correction value
110 HexMinC Min. correction ext. enthalpy
parameters
thermoregulation
compext
111 HexMaxC MAX. correction ext. enthalpy
parameter-set-sensors 23 ProbeURExt Enables external humidity probe: 1=YES / 0=NO
WATER RESET - Opzionale
It allows the automatic correction of the set-point, according to an external signal of 4-20 mA or 0-10 vcc.
The working process is similar to the above mentioned process .
The parameter configuration is necessary.
MENU NUM Parameter name meaning
11 MaxCWRC WR Summer correction max. value
75 WaterReset
Water Reset enabling:
0 = no; 1 = COOL only; 2 = HEAT only; 3 = always
105 SWRMaxC Summer MAX correction signal
parameter
control
waterreset
108 SWRMinC Summer MIN correction signal
parameter-set-sensors 83 TypeWR Inlet signal type: 0=0-10V; 1=4-20mA
SUMMER
°C
set point COMPENSATO
par 108 par 105
4 mA 20 mA
par11
