M07J40G8-00 21/07/08 page 30
Index UNIT_1 – MOD COMP_1 Stata UM
56 Compressor 3 operating time
57 Comp. 3 starts
58 Recovery valve 1=ON / 0=OFF
59 Recovery PREHP delay sec
61 Digital input bit map of a byte
75 Daikin calculated power %
76 PEvapOp bar
77 Taspirazione °C(tenths)
78 Tscarico °C(tenths)
79 Valve opening %
80 SuperHeat °C(tenths)
81 SuperHeatSPOperativo °C(tenths)
82 TempSaturaCondensazione °C(tenths)
Index UNIT_1 – MODEVAP_1 Stata UM
23 Tout1 °C (tenths)
24 Tout2 °C (tenths)
25 Tinput °C (tenths)
26 Pump 1 status 1=ON / 0=OFF
27 Pump 2 status 1=ON / 0=OFF
28 Heater status 1=ON / 0=OFF
62 Digital input bit map of a byte
ALARMS
BEFORE RESETTING THE ALARM, IDENTIFY AND ELIMINATE THE CAUSE OF ITS ACTIVATION.
REPEATED RESETS CAN CAUSE IRREVERSIBLE DAMAGES.
The presence of an alarm is signaled by the icon flashing .
The cumulative block relay activates simultaneously, according to the type of alarm.
Alarms can be reset once the conditions that caused them to trip have been removed.
ALARMS and faults show a potentially dangerous situation for the machine integrity. An immediate analysis is necessary to
detect the causes of the block. A repeated reset can provoke irreversible damage. That is why reset is MANUAL.
PRE-ALARMS AND SIGNALIZATIONS show a situation similar to that one described above. The occurrence of an alarm is
acceptable if it is occasional and/or in transitory situations (for example, when the plant starts). In uncertain cases, please
contact the authorized assistance center.
To enter in the ALARM menu
?
ESC
I
HOME
button F2 ALARM
To select VIEW ALARM
?
ESC
I
HOME
buttons ▲▼ F2 –
F3
To access
?
ESC
I
HOME
button F1 ENTER
To scroll the active alarms
?
ESC
I
HOME
buttons ▲▼ F2 -
F3
To reset the alarm in progress
?
ESC
I
HOME
button F1 ENTER
To go back a level of the menu
?
ESC
I
HOME
button ESC
VIEW ALARM
To visualize the alarm in
progress
STORE ALARM
To visualize the historical
alarm
DEL STORE
To delete the historical
alarm
To go back to the main menu
?
ESC
I
HOME
button HOME
An alarm list is associated with the inputs of each electronic module of the unit.
According to the unit configuration, and then with electronic modules and options, some lists and/or ALARMS can not be used.
