Electrical specifications
14 GENERAL TECHNICAL DATA
1-phase 3-phase 1-phase
12\14\16 kW 12\14\16 kW 5\7\9 kW
Nominal capacity
Refer to the Technical Data
Dimensions HxWxD 1414×1404×405mm 1414×1404×405mm 945×1210×402mm
Weight (without backup heater)
Net weight 158kg 172kg 92kg
Gross weight 178kg 193kg 111kg
Weight (backup heater have be intergrated in the unit)
Net weight 163kg 177kg /
Gross weight 183kg 198kg /
Connections
Water inlet/outlet G5/4"BSP G5/4"BSP G1"BSP
Water drain Hose nipple
Expansion vessel
Volume 5L 5L 2L
Maximum working pressure (MWP) 8 bar 8 bar 8 bar
Pump
Type Water cooled Water cooled Water cooled
No. of Speed 3 3 3
Internal water volume 3.2L 3.2L 2.0L
Pressure relief valve water circuit 3 bar 3 bar 3 bar
Operation range - water side
Heating +12~+60°C +12~+60°C +12~+60°C
Cooling +5~+25°C +5~+25°C +5~+25°C
Operation range - air side
Heating -25~+35°C
Cooling -5~+43°C
Domestic hot water by heat pump -25~+43°C
-5~+46°C
1-phase 5\7\9\12\14\16 3-phase 12\14\16
Standard unit (power supply via unit)
Power Supply 220-240V~ 50Hz 380-415V 3N~ 50Hz
Nominal Running Current See chapter Electrical connections - Specifications of standard wiring components
Backup heater
Power Supply
Nominal Running Current
See chapter Electrical connections - Connection of the backup heater power supply
