CLIVET WSAT-XEE 122 User Manual

M0G140F7-01 06/11/07 pag 39
DIMENSIONS
Sizes 82-102-122
1225
22.5 630 22.5
675
137
1209
11
12
10
1 1
1
10
4
4
3
3
3
3
5
6
7
7
3
1
1
2
2
2
7
9 - 13 9 - 13
700 (14)
700 (15)
700 (14)
700 (15)
8
M N
O P
W1 W2
W4
W3
151.5 326.5
1703
9 - 14
151.5 1225 326.5
21.563021.5
"G"
Size 82 102 122
M
mm 705 700 699
N
mm 998 1003 1004
O
mm 345 345 345
P
mm 330 330 330
Length mm 1703 1703 1703
Depth mm 675 675 675
Height mm 1209 1209 1209
W1
kg 98 99 115
W2
kg 58 59 68
W3
kg 85 87 101
W4
kg 64 65 76
Operating weight kg 305 310 360
Shipping weight kg 315 320 370
(1) COMPRESSOR
(2) FINNED EXCHANGER
(3) HELICAL FANS
(4) PLATE EXCHANGER
(5) EXCHANGER WATER RETURN
(6) EXCHANGER WATER SUPPLY
(7) PUMP
(8) POWER INPUT
(9) LIFTING HOLES
(10) ELECTRICAL PANEL
(11) MICROPROCESSOR KEYBOARD
(12) MAIN ISOLATOR SWITCH
(13) VIBRATION MOUNTS POSITION
(14) MINIMUM DIMENSION FOR A PROPER AIR FLOW TO THE
CONDENSER COIL
(15) MINIMUM DIMENSION FOR A SAFE PASSAGE
(G) BARYCENTRE
VICTAULIC CONNECTION JOINT
