CLIVET WSAT-XEE 122 User Manual

M0G140F7-01 06/11/07 pag 40
Sizes 162-182-222
3
5
6
3
3
3
4
1
5
1
1
10
7
7
3
3
4
1
1
10
2
10
2
9 - 13
33
11
12
7
9 - 13
9 - 13
W1 W2
W4W3
1417
21.5105021.5
1093
1932
2421446244
137
2
M N
O P
700 (14)
700 (15)
700 (14)
700 (15)
8
1050 21.521.5
1446244 242
"G"
Size 162 182 222
M
mm 892 888 889
N
mm 1040 1044 1043
O
mm 520 515 517
P
mm 580 585 583
Length mm 1932 1932 1932
Depth mm 1100 1100 1100
Height mm 1417 1417 1417
W1
kg 166 173 182
W2
kg 99 103 108
W3
kg 146 151 160
W4
kg 109 113 120
Operating weight kg 520 540 570
Shipping weight kg 530 550 580
(1) COMPRESSOR
(2) FINNED EXCHANGER
(3) HELICAL FANS
(4) PLATE EXCHANGER
(5) EXCHANGER WATER RETURN
(6) EXCHANGER WATER SUPPLY
(7) PUMP
(8) POWER INPUT
(9) LIFTING HOLES
(10) ELECTRICAL PANEL
(11) MICROPROCESSOR KEYBOARD
(12) MAIN ISOLATOR SWITCH
(13) VIBRATION MOUNTS POSITION
(14) MINIMUM DIMENSION FOR A PROPER AIR FLOW TO THE
CONDENSER COIL
(15) MINIMUM DIMENSION FOR A SAFE PASSAGE
(G) BARYCENTRE
VICTAULIC CONNECTION JOINT
