pag 46
TECHNICAL DATA
Application: Terminal units
SIZE 17 21 31 41 51 61 71 81 91 101 121
COOLING
Cooling capacity 1 kW 5,97 6,4 7,82 10,4 13,1 16,1 20 22,1 25,6 29 32,4
Compressor power input 1 kW 1,45 1,59 1,91 2,37 3,16 3,85 4,73 4,79 5,79 6,77 7,57
Total power input 2 kW 1,46 1,60 1,92 2,38 3,17 3,86 4,74 4,80 5,80 6,78 7,58
EER kW 4,09 4 4,07 4,37 4,13 4,17 4,22 4,6 4,41 4,28 4,27
ESEER kW 4,28 4,24 4,54 4,85 4,5 4,48 4,6 5,14 4,87 4,76 4,63
HEATING
Heat output 3 kW 6,58 7,17 8,90 11,6 15,7 19,1 23,6 25,3 29,5 34,7 39,3
Compressor power input 3 kW 1,68 1,84 2,38 2,95 3,79 4,54 5,69 6,25 7,05 8,17 9,12
Total power input 2 kW 1,69 1,85 2,39 2,96 3,8 4,55 5,7 6,26 7,06 8,18 9,13
COP kW 3,89 3,88 3,72 3,92 4,13 4,2 4,14 4,04 4,18 4,24 4,3
COMPRESSOR
Type of compressors SCROLL
No. of Compressors 1
Std Capacity control steps 1
Refrigerant charge (C1) kg 0,9 0,9 1,1 1,1 1,4 1,6 1,9 2,5 3,2 3,1 3,3
Refrigerant circuits 1
INTERNAL EXCHANGER
Type of internal exchanger 4 PHE
No. of internal exchangers 1
Water flow rate 1 l/s 0,29 0,31 0,37 0,50 0,63 0,77 0,96 1,06 1,22 1,39 1,55
max Water flow rate l/s 0,48 0,51 0,62 0,83 1,04 1,28 1,59 1,76 2,04 2,31 2,58
Useful pump discharge
head
kPa
55.9 54.2 53.6 43.8 39 61.5 55.8 49.5 44.4 155 134
Water content l 0,6 0,6 0,8 0,8 0,9 1,1 2,2 2,5 2,9 2,9 3,2
EXSTERNAL EXCHANGER
Type of internal exchanger 4 PHE
No. of internal exchangers 1
Water flow rate (Internal
Exchanger)
1 l/s 0,35 0,38 0,46 0,61 0,78 0,95 1,18 1,28 1,50 1,71 1,91
Water content l/s 0,59 0,64 0,77 1,02 1,29 1,59 1,97 2,14 2,5 2,85 3,18
Pressure drop kPa 21 23 22 31 34 35 59 52 53 60 65
CONNECTIONS
Water fittings 5 1"GAS F
EXPANSION VESSEL
Expansion vessel capacity l 1 2
No. of expansion vessels 1
HYDRAULIC CIRCUIT
Max water side pressure kPa 550
Safety valve calibration kPa 600
POWER SUPPLY
Standard power supply 230/1/50 400/3/50+N
DIMENSIONS
Length mm 402 402 402 402 402 573 573 573 573 573 573
Depth mm 602 602 602 602 602 604 604 604 604 604 604
Height mm 785 785 785 785 785 858 858 858 858 858 858
STANDARD UNIT WEIGHTS
Shipping weight kg 79 81 84 88 96 112 126 143 159 160 166
Operating weight kg 81 83 86 90 98 115 129 147 163 164 170
(1) data referred to the following conditions :
internal exchanger water = 12/7°C
external exchanger water = 30/35°C
(2) The total absorbed power is obtained adding the compressors absorbed power + the power absorbed by the auxiliary
circuit.
(3) data referred to the following conditions :
WATER TO INTERNAL EXCHANGER 40/45°C
External exchanger inlet water = 10°C
The water flow in the external exchanger is the same of the cooling operation.
(4) PHE = plates
(5) water connections both source side and utility side
