pag 49
DIMENSIONS
Size 17-51
Size 17 21 31 41 51 (1) COMPRESSOR
(2) INTERNAL EXCHANGER = UTILITY SIDE EXCHANGER
(3) EXTERNAL EXCHANGER = SOURCE SIDE EXCHANGER
(4) ELECTRICAL PANEL
(5) INTERNAL EXCHANGER WATER INLET
(6) INTERNAL EXCHANGER WATER OUTLET
(7) EXTERNAL EXCHANGER WATER INLET
(8) EXTERNAL EXCHANGER WATER OUTLET
(9) SANITARY WATER OUTLET 1"F GAS (OPTIONAL)
(10) UTILITY SIDE PUMP (STANDARD)
(11) EXPANSION VESSEL
(12) WATER SIDE SAFETY VALVE
(13) SOURCE SIDE PUMP (OPTIONAL)
(14) 3 WAYS-VALVE (OPTIONAL)
(15) CLEARANCE ACCESS RECOMMENDED
(16) POWER INPUT
(17) 1/2" GAS CHARGE FITTING
(G) BARYCENTRE
M mm 193 190 195 193 176
N mm 173 173 173 170 187
O mm 169 170 172 168 171
P mm 181 180 182 182 179
Length mm 402 402 402 402 402
Length mm 602 602 602 602 602
Height mm 785 785 785 785 785
W1 kg 22 21 24 25 26
W2 kg 16 19 17 17 21
W3 kg 24 22 26 27 27
W4 kg 18 20 19 19 22
Operating weight kg 81 83 86 90 98
Shipping weight kg 79 81 84 88 96
602
402
119.5 363 119.5
770
785
61
4875757575
W1
W4
W2
W3
119.5 363 119.5
M N
"G"
1
2
3
785 6
11
4
11
10
2
3
9
13
10
14
1
(15)
150
(15)
150
(15)
600
2635026
OP
16
17
260
75
12
