(2) Wheel diameter selection
After entering the correct password, the display will enter into the wheel diameter
setting interface, as mentioned above. The selected wheel diameter parameters, as
shown in figure7-7:
Figure 7-7
By clicking or button, you can select the corresponding wheel diameter
to ensure the accuracy of display speed and distance indication. The factory default
wheel diameter is 26C. The wheel diameter setting is shown in figure7-8: ( the wheel
diameter in the figure is 26C)
Figure 7-8
