SMART CONTROL WHEEL
MACRO KEYS
MEDIA HOTKEYS
WINDOWS® LOCKOUT KEY
FACTORY RESET
Pressing the Fn key (F) + Smart Control Wheel (B)
will cycle through the available modes with the color
changing to indicate the current mode.
After selecting a mode, rotate the wheel left, right, or
click to adjust mode settings.
Macros can be recorded at any time (without software) via on board commands. The keyboard supports a
maximum of 16 key combinations per macro.
The macro functions: Select All / Copy / Paste / Cut are preprogrammed into the 4 macro M-keys (E).
To assign a new macro function, follow these steps:
To clear all custom macros and restore factory settings, press the Fn key (F) + “Esc” key and hold for 3
seconds.
1) Press the Fn key (F) + any single macro M-key (E) to start recording.
2) The “M” LED indicator will flash and the new key combination is ready to be recorded. Enter a new
macro key combination.
3) Press the Fn key (F) + the same macro M-key (E) again to save the recording. The “M” LED indicator
will flash 3 times indicating the macro was successfully saved.
Fn + F1
Fn + F2
Fn + F3
Fn + F4
Fn + F5
Windows lockout key (C) disables the Windows®
key.
Media hotkeys can be accessed by pressing the
Fn key (F) + a media hotkey (A).
Media Player
Play/Pause
Stop
Previous
Next
To return the keyboard to its factory settings, press the Fn key (F) + “Esc” key and hold for 3 seconds.
Note: All custom programmed macros and backlight colors will be erased when the keyboard is returned to
factory settings.
Volume
Application
Scroll
Brightness
White
Red
Blue
Green
MODE
COLOR
Up / Down
Switch
Up / Down
Adjust
Brightness
Mute
Select
Change
Color
-
(click)
ENGLISH
