Technical Specifications
Performance
All Models
Output Power Total output power 1 kW, all channels
1
Output Voltage 70 V or 100 V (rms)
Frequency Response 20 Hz to 20 kHz, +/-0.5 dB
High Pass Filter
-3 dB @ 65 Hz via rear panel switches
-3 dB @ 20 Hz to 200 Hz via DSP configuration
Distortion 0.03%THD @1 kHz, 1 dB below rated output
Noise -94 dB, 22 Hz to 22 kHz
Crosstalk
< -90 dB @1 kHz, -82 dB @10 kHz adjacent channels
<-107 dB @1 kHz, -93 dB @10 kHz non-adjacent channels
All tested with 125 W load
Inputs
Connectors 3-pole 3.5 mm-pitch plug-in screw-terminal connectors
Sensitivity 0 dBu (0.775 V
rms
)
Input Impedance 10 kohms (balanced); 5 kohms (unbalanced)
General
Output connectors 2-pole 5 mm-pitch plug-in screw-terminal connectors
Remote level control connectors 3-pole 5 mm-pitch plug-in screw-terminal connectors
Compatible with Cloud RL Series remote control plates
Power input 85 to 264 V AC, 40 to 60 Hz
Mains protection Class 3T 250 V fuse, 20 x 5 mm, rating T8A
Normal Operating Temperature
0 °C to 35 °C (Note performance and specifications cannot be guaranteed outside this
range)
Power Consumption
CV2500 CV4250 CV8125
Standby
2
2.34 W, 12.4 VA 2.43 W, 24.0 VA 2.5 W, 24.4 VA
Idle
3
27.1 W, 46.7 VA 38.9 W, 60.0 VA 59.7 W, 89.3 VA
1/8th power
4
164.2 W, 201.3 VA 187.4 W, 227.2 VA 207.0 W, 248.8 VA
1/3rd power
5
380.7 W, 421.1 VA 330.1 W, 368.8 VA 352.6 W, 387.5 VA
Heat Loss
Standby
2
8.4 KJ/hr
(8.0 BTU/hr)
8.7 KJ/hr
(8.3 BTU/hr)
9.1 KJ/hr
(8.7 BTU/hr)
Idle
3
97.3 KJ/hr
(92.5 BTU/hr)
140.1 KJ/hr
(132.9 BTU/hr)
215.0 KJ/hr
(203.9 BTU/hr)
1/8th power
4
179 KJ/hr
(169.7 BTU/hr)
217.9 KJ/hr
(206.7 BTU/hr)
278.7 KJ/hr
(264.3 BTU/hr)
1/3rd power
5
293.3 KJ/hr
(278.7 BTU/hr)
263.5 KJ/hr
(249.9 BTU/hr)
334.4 KJ/hr
(317.1 BTU/hr)
