LITE Stage Receiver
Specification
Flashing (slowly): On / Flashing (quickly): Pairing
Glowing: Paired and is operating
① ANT
③ SYNC IN
② SYNC OUT
Using multiple receivers (up to 3 at a time), please connect the sync
out of the first unit to the sync in of the second unit (and so on) with
the 3.5mm TRS cable. We recommend to leave 1m distance between
each receiver.
SYNC IN / SYNC OUT Connection diagram
When receivers are syncing with each
other, all receivers will switch to range
boost mode and sync the wireless
signals to avoid interference.
OUT IN OUT IN
